Plants Physiology

Catalogue No. 4012320/2

This Cell scraper, as the name suggests, provides an excellent option for cell scraping purposes in microbiology.
*Length 300 mm.

Catalogue No. 4012320/1

This Cell scraper, as the name suggests, provides an excellent option for cell scraping purposes in microbiology.
*Length 240 mm.

Catalogue No. 4012400/1

Takes one revolution every 15 minutes for 24 hours in vertical or horizontal position. The plant is sown in the pot, with clock movement on heavy metal base.With ON/OFF mechanism.

Catalogue No. 4012600

For experiments in phototropism with seedlings. Three-chambered case of wood with to accept a variety of shutters. The right-hand chamber has windows in the top and back end, when used with a clear front window, acts as a control chamber. Supplied with opaque shutter, a slot shutter to admit light from one direction only, the clear windows for the control chamber, one orange and one blue filter to show the effect of excluding various parts of the spectrum. Complete with three glass containers for seedlings. Dimensions overall 180 × 530 × 180mm approx. (height × width × depth).

Catalogue No. 4012100/1

Comprises a graduated, narrow bore, horizontal glass measuring tube with a vessel for a plant shoot at one end and having a vertical limb with a stopcock and a funnel fitted by a ground glass joint. Mounted on a wooden stand. For Demonstration, of transpiration rates and rates of water absorption by a cut shoot under various external conditions. A plant shoot is sealed into a stopper which fits the end tube, and the whole apparatus is filled with water, the open end of the capillary tube, which is graduated in millimetres, dipping into a beaker of water. The position of the air bubble may easily be adjusted by opening the glass stopcock to admit water from the central reservoir. The whole apparatus is mounted on a varnished wooden base by spring clips. Comprises a graduate, narrow bore, horizontal glass measuring tubes with a vessel for plant shot at one end and having a vertical limb with a Teflon stopcock and a funnel fitted by a ground glass joint. Height to top of reservoir 170mm, Diameter of reservoir 20mm Length, overall 320mm, Base 320x80mm (L x W), Capillary bore 1mm.

Catalogue No. 4012100/2

Comprises a graduated, narrow bore, horizontal glass measuring tube with a vessel for a plant shoot at one end and having a vertical limb with a stopcock and a funnel fitted by a ground glass joint. Mounted on a wooden stand. For Demonstration, of transpiration rates and rates of water absorption by a cut shoot under various external conditions. A plant shoot is sealed into a stopper which fits the end tube, and the whole apparatus is filled with water, the open end of the capillary tube, which is graduated in millimetres, dipping into a beaker of water. The position of the air bubble may easily be adjusted by opening the glass stopcock to admit water from the central reservoir. The whole apparatus is mounted on a varnished wooden base by spring clips. Comprises a graduate, narrow bore, horizontal glass measuring tubes with a vessel for plant shot at one end and having a vertical limb with a Teflon stopcock and a funnel fitted by a ground glass joint. Height to top of reservoir 170mm, Diameter of reservoir 20mm Length, overall 320mm, Base 320x80mm (L x W), Capillary bore 1mm.

Catalogue No. 4012250

This apparatus is designed for exploring the phenomena of osmosis and concept of osmotic pressure at elementary levels. Comprises a semipermeable membrane sealing the open mouth of thistle funnel having an indicator tube, which can be positioned in a reservoir. Supplied complete with dropping pipette.

Catalogue No. 4012200

For measuring and analyzing gas evolved by the plants such as Elodea. Comprise two syringes connected to a collecting tube through a 3-way tap. This arrangement enables the gas to be drawn along the capillary tube by one syringe for analysis. The apparatus is mounted on a back board about 240 x 100mm, capillary bore 1 mm.
